Description
Power, efficiency and high performance are some of the synonyms of this module. It has a maximum power of 40,000 Watts RMS at 0.5 ohm, thermal protection and anti-short-circuit. It is powered by batteries in series, as it uses batteries as its source of power. It is a unique line in its category, delivering extremely high power in mid and large car audio systems.
Description
Power, efficiency and high performance are some of the synonyms of this module. It has a maximum power of 40,000 Watts RMS at 0.5 ohm, thermal protection and anti-short-circuit. It is powered by batteries in series, as it uses batteries as its source of power. It is a unique line in its category, delivering extremely high power in mid and large car audio systems. Stands out in quality from sub-bass to mid-highs. High performance in timbres and audio quality.
| NUMBER OF CHANNELS |
(PT) 01 |
| OUTPUT VOLTAGE |
227VDC @ 0.5 Ohm - 18 batteries |
| INPUT SENSITIVITY |
(PT) 330mV ( Level 100%) @ 0.5 Ohm |
| AUX INPUT STANDARD |
(PT) 0.3% |
| SIGNAL TO NOISE RATIO |
>95dB |
| FREQUENCY RESPONSE |
10Hz ~ 15KHz (0.5dB) |
| EFFICIENCY |
92% @ 0.5 Ohm (full power) |
| INPUT IMPEDANCE |
27K Ohms |
| PROTECTION SYSTEM |
Short-Circuit to Output,
Short on output compared to GND,
Low impedance at output,
High/Low supply voltage
Thermal protection** |
| POWER SUPPLY VOLTAGE |
140VDC |
| POWER SUPPLY VOLTAGE |
275VDC |
| CONSUMPTION AT REST |
110mA |
| MAXIMUM MUSIC CONSUMPTION @ 0.5 OHM |
91.5A |
| MAXIMUM SINUSOIDAL CONSUMPTION @ 0.5 OHM (100HZ) |
183A |
| DIMENSIONS (H X W X D) |
8.98" x 2.52" x 22.07" (228 x 64 x 561mm) |
| WEIGHT |
12.54lb (5.70Kg) |
| MAXIMUM OUTPUT POWER @ 227 VDC- 0.5 OHM* |
40.000W RMS |
| EAN |
7898556844727 |
