Description
The 800.5 EVO6 is an ultra-compact and modern amplifier designed to deliver a total power of 800W RMS across 5 channels. Featuring patented, exclusive technologies, this amplifier ensures superior sound quality, providing a cleaner and more accurate audio experience. With outstanding performance and high efficiency, the 800.5 EVO6 is the perfect choice for demanding audio projects.
Available in 4-ohm version.
General Specifications:
800.5 EVO6 – 4 OHMS
-
Power @ 4Ω: 4 x 100W RMS
-
Power @ 8Ω: 4 x 66W RMS
-
Subwoofer (4Ω): 1 x 400W
-
Bridge Power @ 8Ω: 2 x 200W RMS
-
Subwoofer @ 8Ω: N/A
-
Frequency Response (-3dB):
- General: 80Hz ~ 25kHz
- Subwoofer: 5Hz ~ 80Hz
-
Low-Pass Filter (12dB/octave): 80Hz
-
High-Pass Filter (12dB/octave): 80Hz
-
Operating Voltage: 9V ~ 16V
-
Signal-to-Noise Ratio:
- General: 103.88dB
- Subwoofer: 102dB
-
Input Sensitivity (RCA): 0.2V ~ 2V
-
Music Power Consumption: 39A
-
Resistive Load Consumption: 78.7A
-
Total Efficiency: 80%
-
Damping Factor (@100Hz nominal impedance): 200
-
Power Cable: 10mm² (7 AWG)
-
Speaker/Subwoofer Cable:
- Speakers: 1.5mm² (15 AWG)
- Subwoofer: 2.5mm² (13 AWG)
-
Recommended Fuse (musical use): 40A
-
Recommended Battery (minimum): 60Ah
-
Dimensions:
- Width: 15.7 cm
- Length: 11.7 cm
- Height: 5.5 cm
-
Weight: 0.75 kg
