Taramps Audio Mixer T 0202 Automotive Sound Desk

Description

Description

Sound Table T 0202, control your sound system with much more tranquility and simplicity. The two input channels, with 4 connections, allow for different mixing possibilities, including: microphone, players, musical instruments (eg keyboard and guitar), etc. With gain and level adjustment on all channels, it allows your gain structure to be impeccable. In addition, to give that special touch to the “regulation”, all channels have tonal equalization in 4 bands (bass, low mid, high mid and high). And the visual indication of each of the channels with LEDs for On, Clipping and Signal could not be missing, also having an output VU where we can guarantee more sound volume without unwanted distortions, guaranteeing a very low level of noise or hiss.
Through the two output channels, we can send audio signal to peripherals such as equalizers, audio processors or directly to amplifiers. It is also possible to use the auxiliary output to send audio to other systems, making it possible to control the volume and adjust the phase, correcting possible cancellations.
T 0202, quality and control at your fingertips.


TECHNICAL INFORMATION
EAN 7898556849036
ADDITIONAL INFORMATION
Frequency Response (-3dB): 2Hz ~ 76Khz

Total Harmonic Distortion: <0.009% (THD)

Signal to Noise Ratio (SNR): 112dB

Input Sensitivity:
Line (RCA) Min: 840mV~Max 15.6mV
Line/MIC (P10) ) Min: 2.65mV ~ Max 44.7mV


4 EQ bands per channel:
High +15dB (18KHz)
Mid High +15dB (2.4KHz)
Mid Low +15dB (240Hz)
LOW +15dB (30Hz

) channels:
Line (RCA): Unbalanced 10K Ohms
Line/MIC (P10): Unbalanced 2.5K Ohms

Max. on inputs without distortion:
Line (RCA): 3 Vac
Line/MIC (P10): 1 Vac

Output impedance:
Main Out: 47R
Aux Out: 47R

Maximum output level:
Main Out: 18 dBu/6.3 Vac
Aux Out: 18 dBu/6.3 Vac

Supply Voltage (POWER): 9 ~ 16 Vdc

Maximum Consumption with REM OUT = 0mA: 280 mA

Remote Input (Connector REM): 9 ~ 16 Vdc

Remote Output (REM Connector): 350 mA

Dimensions (WxHxD): 120 × 42 x 220 mm

Weight: 0.60 Kg


Taramps Audio Mixer T 0202 Automotive Sound Desk

Product form

Description Sound Table T 0202, control your sound system with much more tranquility and simplicity. The two input channels, with 4... Read more

$156.00 $127.00

      Description

      Description

      Sound Table T 0202, control your sound system with much more tranquility and simplicity. The two input channels, with 4 connections, allow for different mixing possibilities, including: microphone, players, musical instruments (eg keyboard and guitar), etc. With gain and level adjustment on all channels, it allows your gain structure to be impeccable. In addition, to give that special touch to the “regulation”, all channels have tonal equalization in 4 bands (bass, low mid, high mid and high). And the visual indication of each of the channels with LEDs for On, Clipping and Signal could not be missing, also having an output VU where we can guarantee more sound volume without unwanted distortions, guaranteeing a very low level of noise or hiss.
      Through the two output channels, we can send audio signal to peripherals such as equalizers, audio processors or directly to amplifiers. It is also possible to use the auxiliary output to send audio to other systems, making it possible to control the volume and adjust the phase, correcting possible cancellations.
      T 0202, quality and control at your fingertips.


      TECHNICAL INFORMATION
      EAN 7898556849036
      ADDITIONAL INFORMATION
      Frequency Response (-3dB): 2Hz ~ 76Khz

      Total Harmonic Distortion: <0.009% (THD)

      Signal to Noise Ratio (SNR): 112dB

      Input Sensitivity:
      Line (RCA) Min: 840mV~Max 15.6mV
      Line/MIC (P10) ) Min: 2.65mV ~ Max 44.7mV


      4 EQ bands per channel:
      High +15dB (18KHz)
      Mid High +15dB (2.4KHz)
      Mid Low +15dB (240Hz)
      LOW +15dB (30Hz

      ) channels:
      Line (RCA): Unbalanced 10K Ohms
      Line/MIC (P10): Unbalanced 2.5K Ohms

      Max. on inputs without distortion:
      Line (RCA): 3 Vac
      Line/MIC (P10): 1 Vac

      Output impedance:
      Main Out: 47R
      Aux Out: 47R

      Maximum output level:
      Main Out: 18 dBu/6.3 Vac
      Aux Out: 18 dBu/6.3 Vac

      Supply Voltage (POWER): 9 ~ 16 Vdc

      Maximum Consumption with REM OUT = 0mA: 280 mA

      Remote Input (Connector REM): 9 ~ 16 Vdc

      Remote Output (REM Connector): 350 mA

      Dimensions (WxHxD): 120 × 42 x 220 mm

      Weight: 0.60 Kg
