Taramps Audio Mixer T 0302 Player Automotive Sound Desk

Description

Description

AT 0302 Player is the first “Table Player” from Taramps. In addition to controlling and mixing your sound system, it is capable of playing your favorite playlist without the need to use a “conventional player”. The integrated Player has a BT connection to connect your smartphone, tablet and other devices. It also has a USB input, FM reception and headphone output. And to make it even better, we included the long-distance remote control, which allows you to increase or decrease the volume, change tracks and folders, among other functions, when using the Player function.
Among the product's main applications, we can mention the famous "Bob Boxes" and the most varied automotive sound systems. Simplicity in installation and versatility of use are synonymous with this product.


TECHNICAL INFORMATION
EAN 7898556849241
ADDITIONAL INFORMATION
Frequency Response (-3dB): 2Hz ~ 76Khz

Total Harmonic Distortion: <0.009% (THD)

Signal to Noise Ratio (SNR): 112dB

Channel 1 Input Sensitivity:
Mic (XLR) Min: 500mV ~ Max 7mV
Line (P10) Min: 620mV ~ Max 7.6mV

Channel 2/3 input sensitivity:
Line (P10/RCA) Min: 2.55V ~ Max: 60mV

4 EQ bands per channel:
High +15dB (12KHz)
Mid High +15dB ( 2.5KHz)
Mid Low +15dB (300Hz)
LOW +15dB (80Hz)

Channel 1 input impedance:
Mic (XRL): Unbalanced 4K Ohms
Balanced 8K Ohms
Line (P10): Unbalanced 8.5K Ohms
Balanced 17KOhms

Input impedance of channels 2/3:
Line (P10): Unbalanced 10K Ohms
Line (RCA): Unbalanced 10K Ohms

Bluetooth Version: 4.0 SBC / A2DP

Audio Format: Mp3 / WMA

Maximum Bitrate: 320Kbps

FM: 87.5MHz to 108MHz

Equalization Mode: POP, ROCK, JAZZ, COUNTRY, NORMAL

Remote control: 433.5MHz 10dBm

Output impedance:
Main Out (P10/RCA): 47R
Aux Out (P10/RCA): 47R

Maximum output level:
Main Out (P10/RCA): 18 dBu/6.3 Vac
Aux Out (P10/RCA): 18 dBu/6.3 Vac

Supply Voltage (POWER): 9 ~ 15 Vdc

Maximum Consumption: 600 mA

Remote Input (REM Connector): 9 ~ 15 Vdc

Remote Output (REM Connector): 350 mA

Dimensions (WxHxD): 148 × 42 x 220 mm

Weight: 0.75 Kg


Taramps Audio Mixer T 0302 Player Automotive Sound Desk

Product form

Description AT 0302 Player is the first “Table Player” from Taramps. In addition to controlling and mixing your sound system, it... Read more

$177.00 $159.00

      Description

      Description

      AT 0302 Player is the first “Table Player” from Taramps. In addition to controlling and mixing your sound system, it is capable of playing your favorite playlist without the need to use a “conventional player”. The integrated Player has a BT connection to connect your smartphone, tablet and other devices. It also has a USB input, FM reception and headphone output. And to make it even better, we included the long-distance remote control, which allows you to increase or decrease the volume, change tracks and folders, among other functions, when using the Player function.
      Among the product's main applications, we can mention the famous "Bob Boxes" and the most varied automotive sound systems. Simplicity in installation and versatility of use are synonymous with this product.


      TECHNICAL INFORMATION
      EAN 7898556849241
      ADDITIONAL INFORMATION
      Frequency Response (-3dB): 2Hz ~ 76Khz

      Total Harmonic Distortion: <0.009% (THD)

      Signal to Noise Ratio (SNR): 112dB

      Channel 1 Input Sensitivity:
      Mic (XLR) Min: 500mV ~ Max 7mV
      Line (P10) Min: 620mV ~ Max 7.6mV

      Channel 2/3 input sensitivity:
      Line (P10/RCA) Min: 2.55V ~ Max: 60mV

      4 EQ bands per channel:
      High +15dB (12KHz)
      Mid High +15dB ( 2.5KHz)
      Mid Low +15dB (300Hz)
      LOW +15dB (80Hz)

      Channel 1 input impedance:
      Mic (XRL): Unbalanced 4K Ohms
      Balanced 8K Ohms
      Line (P10): Unbalanced 8.5K Ohms
      Balanced 17KOhms

      Input impedance of channels 2/3:
      Line (P10): Unbalanced 10K Ohms
      Line (RCA): Unbalanced 10K Ohms

      Bluetooth Version: 4.0 SBC / A2DP

      Audio Format: Mp3 / WMA

      Maximum Bitrate: 320Kbps

      FM: 87.5MHz to 108MHz

      Equalization Mode: POP, ROCK, JAZZ, COUNTRY, NORMAL

      Remote control: 433.5MHz 10dBm

      Output impedance:
      Main Out (P10/RCA): 47R
      Aux Out (P10/RCA): 47R

      Maximum output level:
      Main Out (P10/RCA): 18 dBu/6.3 Vac
      Aux Out (P10/RCA): 18 dBu/6.3 Vac

      Supply Voltage (POWER): 9 ~ 15 Vdc

      Maximum Consumption: 600 mA

      Remote Input (REM Connector): 9 ~ 15 Vdc

      Remote Output (REM Connector): 350 mA

      Dimensions (WxHxD): 148 × 42 x 220 mm

      Weight: 0.75 Kg
