Description
Taramps proudly presents the HD2000, an amplifier with the tradition and quality of one of the most renowned Taramps lines. If you are looking for power and versatility, It’s the perfect amplifier for you. But, what about its power? It delivers 2000 WRMS at 12.6V DC (Nominal power with sinusoidal signal from 60Hz to 1KHz and THD <= 1% at the output). Right! But why is it versatile? To start with, it is available at 1 Ohm, 2 Ohms and 4 Ohms. Certainly, one of them will match your sound project. It has a wide frequency response, which allows you to use it to run: Subwoofers, woofers, midrange, midrange 6×9”, full range speakers, phenolic drivers, titanium drivers, super tweeters, among others. It means that you can use it in car audio, trunk speakers, sound walls, 3-way systems, residential speakers, etc. Feel free to use your creativity to make the most of this incredible product. And there is more. It also features Level, Crossover (HPF and LPF) and Bass boost adjustment to Boost up the bass. All made to get your sound well tuned and reach the perfect beat. And we couldn’t miss the On, Clip and protection LED indicators, which are replicated by the M1 LED monitor, an exclusive accessory that comes as a courtesy. Now It will be easy to check what´s going on with your amplifier while it is operating. Live a fantastic sound experience, with the best cost benefit!
| OPERATION CLASS |
Class D |
| NUMBER OF CHANNELS |
01 |
| MAXIMUM POWER |
@12.6VDC - 1 Ohm: 2000 Watts RMS
@12.6VDC - 2 Ohms: 1100 Watts RMS |
| INPUT SENSITIVITY |
220mV |
| SIGNAL TO NOISE RATIO |
>88dB |
| FREQUENCY RESPONSE |
10Hz ~ 20 kHz (-3dB) |
| CROSSOVER HIGH PASS (HPF) |
10Hz ~ 80 Hz (-12dB/8ª) Variable |
| CROSSOVER LOW PASS (LPF) |
80Hz ~ Full (-12dB/8ª) Variable |
| BASS BOOST |
0 ~ 10.5dB (50 Hz) |
| THERMAL MANAGEMENT |
Smart Cooler (fan controlled by temperature or audio, with 3 speeds) |
| INPUT IMPEDANCE |
10K Ohms |
| OUTPUT IMPEDANCE |
1 Ohm |
| PROTECTION SYSTEM |
Output Short circuit / High or Low supply voltage / Thermal protection |
| MIN. SUPPLY VOLTAGE |
9 VDC |
| MAXIMUM POWER SUPPLY VOLTAGE |
16 VDC |
| CONSUMPTION AT REST |
1.5A |
| MAXIMUM MUSIC CONSUMPTION |
@12,6VDC: 117.5A |
| MAXIMUM CONSUMPTION IN SINUSOIDAL SIGNAL |
235 A |
| DIMENSIONS (WXHXD) |
228 x 64 x 186mm (8.98" x 2.52" x 7.32" |
| WEIGHT |
1.92 Kg (4.22lb) |
| EAN |
7898556848152 |
| OPERATION CLASS |
Class D |
| NUMBER OF CHANNELS |
01 |
| MAXIMUM POWER |
@12,6 VDC - 2 Ohms: 2000W RMS
@12,6 VDC - 4 Ohms: 1400 Watts RMS
@12,6 VDC - 8 Ohms: 515 Watts RMS |
| INPUT SENSITIVITY |
220mV |
| SIGNAL TO NOISE RATIO |
>88dB |
| FREQUENCY RESPONSE |
10Hz ~ 20KHz (-3dB) |
| CROSSOVER HIGH PASS (HPF) |
10 ~ 80Hz (-12dB/8ª) Variable |
| CROSSOVER LOW PASS (LPF) |
80Hz ~ Full (-12dB/8ª) Variable |
| BASS BOOST |
0 ~ 10.5dB (50 Hz) |
| THERMAL MANAGEMENT |
Smart Cooler (fan controlled by temperature or audio, with 3 speeds) |
| INPUT IMPEDANCE |
10K Ohms |
| OUTPUT IMPEDANCE |
2 Ohms |
| PROTECTION SYSTEM |
Output Short circuit / High or Low supply voltage / Thermal protection |
| MIN. SUPPLY VOLTAGE |
9 VDC |
| MAXIMUM POWER SUPPLY VOLTAGE |
16 VDC |
| CONSUMPTION AT REST |
1.6A |
| MAXIMUM MUSIC CONSUMPTION |
@12,6VDC: 100A |
| MAXIMUM CONSUMPTION IN SINUSOIDAL SIGNAL |
200A |
| DIMENSIONS (WXHXD) |
228 x 64 x 186mm (8.98" x 2.52" x 7.32") |
| WEIGHT |
1.92 Kg (4.22lb) |
| EAN |
7898556848169 |
| OPERATION CLASS |
Class D |
| NUMBER OF CHANNELS |
01 |
| MAXIMUM POWER |
@12,6 VDC - 4 Ohms: 2000 Watts RMS
@12,6 VDC - 8 Ohms: 1300 Watts RMS |
| INPUT SENSITIVITY |
220mV |
| SIGNAL TO NOISE RATIO |
>88dB |
| FREQUENCY RESPONSE |
10Hz ~ 20KHz (-3dB) |
| CROSSOVER HIGH PASS (HPF) |
10 ~ 80Hz (-12dB/8ª) Variable |
| CROSSOVER LOW PASS (LPF) |
80Hz ~ Full (-12dB/8ª) Variable |
| BASS BOOST |
0 ~ 10.5dB (50 Hz) |
| THERMAL MANAGEMENT |
Smart Cooler (fan controlled by temperature or audio, with 3 speeds) |
| INPUT IMPEDANCE |
10K Ohms |
| OUTPUT IMPEDANCE |
4 Ohms |
| PROTECTION SYSTEM |
Output Short circuit / High or Low supply voltage / Thermal protection |
| MIN. SUPPLY VOLTAGE |
9 VDC |
| MAXIMUM POWER SUPPLY VOLTAGE |
16 VDC |
| CONSUMPTION AT REST |
1.9A |
| MAXIMUM MUSIC CONSUMPTION |
@12,6VDC: 100A |
| MAXIMUM CONSUMPTION IN SINUSOIDAL SIGNAL |
200A |
| DIMENSIONS (WXHXD) |
228 x 64 x 186mm (8.98" x 2.52" x 7.32") |
| WEIGHT |
1.92 Kg (4.22lb) |
| EAN |
7898556848176 |
