Taramps presents the amplifier module MD 12000.1 in the 0.5 ohm version. It has been carefully designed with the highest technology, offering high performance and quality for most types  of car audio systems, covering the whole frequency range, in other words, it is a FULL RANGE module. It is a mono amplifier, has a channel with a maximum power of 12000 Watts RMS. Welcome to the audio world by Taramps. TECHNICAL INFORMATION OPERATION CLASS Class D NUMBER OF CHANNELS 01 MAXIMUM POWER @ 12.6 VDC - 0.5 OHM: 12000W RMS@ 12.6 VDC - 1 OHM: 7200W RMS INPUT SENSITIVITY 220mV SIGNAL TO NOISE RATIO >95dB FREQUENCY RESPONSE 10 Hz ~5 kHz (-3dB) CROSSOVER HIGH PASS (HPF) 10 Hz ~90 Hz (-12dB/8th) Variable CROSSOVER LOW PASS (LPF) 90 Hz ~5 kHz (-12dB/8th) Variable BASS BOOST Freq.: 35 Hz ~55 HzBoost: 0 ~10dB EFFICIENCY 79% INPUT IMPEDANCE 15K ohms OUTPUT IMPEDANCE 0.5 ohm PROTECTION SYSTEM Output Short circuit, Output Short circuit in relation to the GND, Low Impedance Protection / High or Low voltage Protection / Thermal protection MIN. SUPPLY VOLTAGE 9VDC MAXIMUM POWER SUPPLY VOLTAGE 16VDC CONSUMPTION AT REST 3.6A MAXIMUM MUSIC CONSUMPTION 602.5A MAXIMUM CONSUMPTION IN SINUSOIDAL SIGNAL 1205A DIMENSIONS (WXHXD) 8.98" x 2.75" x 21.65" (228 x 70 x 550mm) WEIGHT 17.52 lbs (7.95 kg) EAN 7898556845113

Read more less

Description The Taramps MD 1800.1 in the 1,2,4-ohm version has been carefully designed with the highest technology, offering high efficiency and performance for various types of car audio systems. This amplifier covers the whole frequency range, that is, it is a FULL RANGE module. It is classified as mono and has a channel with a maximum power of 1800-Watts RMS. Welcome to Taramps audio world. TECHNICAL INFORMATION OPERATION CLASS Class D NUMBER OF CHANNELS 01 MAXIMUM POWER @ 12.6 VDC - 1 OHM: 1800W RMS@ 12.6 VDC - 2 OHMS: 1410W RMS INPUT SENSITIVITY 220 mV SIGNAL TO NOISE RATIO >88dB FREQUENCY RESPONSE 10Hz ~ 20KHz (-3dB) CROSSOVER HIGH PASS (HPF) 10Hz ~ 80Hz (-12dB/8ª) Variable CROSSOVER LOW PASS (LPF) 80Hz ~Full (-12dB/8ª) Variable BASS BOOST 0 ~ 10.5dB (50Hz) THERMAL MANAGEMENT Smart Cooler (fan controlled by temperature or audio, with 3 speeds) EFFICIENCY 78% INPUT IMPEDANCE 10k OHMS OUTPUT IMPEDANCE 1 OHM PROTECTION SYSTEM Output Short / High/Low Supply Voltage / Thermal Protection MIN. SUPPLY VOLTAGE 9VDC MAXIMUM POWER SUPPLY VOLTAGE 16VDC CONSUMPTION AT REST 1.7 A MAXIMUM MUSIC CONSUMPTION 91 A MAXIMUM CONSUMPTION IN SINUSOIDAL SIGNAL 182 A DIMENSIONS (WXHXD) 8.98" x 2.76" x 7.40" (228 x 70 x 188mm) WEIGHT 4.80lb (2.18kg) EAN 7898556844390 TECHNICAL INFORMATION OPERATION CLASS Class D NUMBER OF CHANNELS 01 MAXIMUM POWER @ 12.6 VDC - 2 OHMS: 1800W RMS@ 12.6 VDC - 4 OHMS: 1100W RMS@ 12.6 VDC - 8 OHMS: 515W RMS INPUT SENSITIVITY 220mV SIGNAL TO NOISE RATIO >88dB FREQUENCY RESPONSE 10Hz ~ 20KHz (-3dB) CROSSOVER HIGH PASS (HPF) 10Hz ~ 80Hz (-12dB/8ª) Variable CROSSOVER LOW PASS (LPF) 80Hz ~ Full (-12dB/8ª) Variable BASS BOOST 0 ~ 10dB (50Hz) THERMAL MANAGEMENT Smart Cooler (Cooler powered by temperature or audio at 3 speeds) EFFICIENCY 78% INPUT IMPEDANCE 10K ohms OUTPUT IMPEDANCE 2 ohms PROTECTION SYSTEM Short circuit at the output, low/high supply voltage, thermal protection. MIN. SUPPLY VOLTAGE 9 VDC MAXIMUM POWER SUPPLY VOLTAGE 16VDC CONSUMPTION AT REST 1.7 A MAXIMUM MUSIC CONSUMPTION 91 A MAXIMUM CONSUMPTION IN SINUSOIDAL SIGNAL 182 A DIMENSIONS (WXHXD) 8.6" x 2.75" x 7.40" (228 x 70 x 188mm) WEIGHT 4.80lb (2,18kg) EAN 7898556844376 TECHNICAL INFORMATION OPERATION CLASS Classe D NUMBER OF CHANNELS 01 MAXIMUM POWER @ 12.6 VDC - 4 OHMS: 1800W RMS@ 12.6 VDC - 8 OHMS: 1050W RMS INPUT SENSITIVITY 220 mV SIGNAL TO NOISE RATIO >88dB FREQUENCY RESPONSE 10Hz ~ 20KHz (-3dB) CROSSOVER HIGH PASS (HPF) 10Hz ~ 80Hz (-12dB/8ª) Variable CROSSOVER LOW PASS (LPF) 80Hz ~Full (-12dB/8ª) Variable BASS BOOST 0 ~ 10.5dB (50Hz) THERMAL MANAGEMENT Smart Cooler (fan controlled by temperature or audio, with 3 speeds) EFFICIENCY 84% INPUT IMPEDANCE 10K ohms OUTPUT IMPEDANCE 4 ohms PROTECTION SYSTEM Short-Circuit to Output, Short on output compared to GND, Low impedance at output, low/high supply voltage and Thermal protection. MIN. SUPPLY VOLTAGE 9VDC MAXIMUM POWER SUPPLY VOLTAGE 16VDC CONSUMPTION AT REST 1.5 A MAXIMUM MUSIC CONSUMPTION 85 A MAXIMUM CONSUMPTION IN SINUSOIDAL SIGNAL 170 A DIMENSIONS (WXHXD) 8.98" x 2.76" x 7.40" (228 x 70 x 188mm) WEIGHT 4.80lb (2,18Kg) EAN 7898556844383

Read more less

Description The Taramps MD 250.1 in the 4, 2-ohm version has been carefully designed with the highest technology, offering high efficiency and performance for various types of car audio systems. This amplifier covers the entire frequency range, that is, it is a FULL RANGE module. It is classified as mono and has a channel with a maximum power of 250-Watts RMS. Welcome to Taramps audio world. TECHNICAL INFORMATION OPERATION CLASS Class D NUMBER OF CHANNELS 01 MAXIMUM POWER @ 13.8 VDC - 2 OHMS: 250W RMS@ 13.8 VDC - 4 OHMS: 160W RMS INPUT SENSITIVITY 220mV SIGNAL TO NOISE RATIO >90dB FREQUENCY RESPONSE 10Hz ~ 20KHz (-3dB) CROSSOVER HIGH PASS (HPF) 10Hz ~ 80Hz (-12dB/8ª) Variable CROSSOVER LOW PASS (LPF) 80Hz ~ Full (-12dB/8ª) Variable BASS BOOST 0 ~ 10dB (50Hz) INPUT IMPEDANCE 10K ohms OUTPUT IMPEDANCE 2 ohms PROTECTION SYSTEM Output short-circuit / thermal protection MIN. SUPPLY VOLTAGE 9 VDC MAXIMUM POWER SUPPLY VOLTAGE 16VDC CONSUMPTION AT REST 0.5 A MAXIMUM MUSIC CONSUMPTION 12.5 A MAXIMUM CONSUMPTION IN SINUSOIDAL SIGNAL 25 A DIMENSIONS (WXHXD) 5.43" x 1.92" x 5.19" (138 x 49 x 132mm) WEIGHT 1.43lb (0,65kg) EAN 7898556845090   TECHNICAL INFORMATION OPERATION CLASS Class D NUMBER OF CHANNELS 01 MAXIMUM POWER @ 13.8 VDC - 2 OHMS: 250W RMS@ 13.8 VDC - 4 OHMS: 160W RMS INPUT SENSITIVITY 220mV SIGNAL TO NOISE RATIO >90dB FREQUENCY RESPONSE 10Hz ~ 20KHz (-3dB) CROSSOVER HIGH PASS (HPF) 10Hz ~ 80Hz (-12dB/8ª) Variable CROSSOVER LOW PASS (LPF) 80Hz ~ Full (-12dB/8ª) Variable BASS BOOST 0 ~ 10dB (50Hz) INPUT IMPEDANCE 10K ohms OUTPUT IMPEDANCE 4 ohms PROTECTION SYSTEM Short-circuit and thermal protection MIN. SUPPLY VOLTAGE 9 VDC MAXIMUM POWER SUPPLY VOLTAGE 16VDC CONSUMPTION AT REST 0.55 A MAXIMUM MUSIC CONSUMPTION 12 A MAXIMUM CONSUMPTION IN SINUSOIDAL SIGNAL 24 A DIMENSIONS (WXHXD) 5.43" x 1.92" x 5.19" (138 x 49 x 132mm) WEIGHT 1.43lb (0,65kg) EAN 7898556845106

Read more less

The Taramps MD 3000.1 is a high-performance Class D amplifier, designed to deliver exceptional power efficiency while maintaining high sound quality. Available in 1, 2, and 4-ohm versions, this mono-channel amplifier provides 3,000W RMS of real power, making it ideal for a variety of car audio systems. Key Features: 🔹 Full-Range Technology – Covers the entire frequency range (10Hz – 18kHz) for versatile sound applications🔹 High Efficiency – Class D operation ensures low power consumption and optimal performance🔹 Built-in Crossover – Adjustable high-pass (10Hz – 90Hz) and low-pass (90Hz – 18kHz) filters🔹 Bass Boost Control – Adjustable from 0 to 10dB with variable frequency (35 – 55Hz)🔹 Advanced Protection System – Short-circuit protection, thermal protection, and low/high voltage safeguards🔹 Compact & Durable Design – Built for reliability in demanding conditions Technical Specifications: ✔ Operation Class: D✔ Number of Channels: 1 (Mono)✔ Maximum Power Output: 1 Ohm Version: 3,000W RMS @ 12.6V 2 Ohm Version: 3,000W RMS @ 12.6V 4 Ohm Version: 3,000W RMS @ 12.6V✔ Frequency Response: 10Hz – 18kHz (-3dB)✔ Signal-to-Noise Ratio: >90dB✔ Input Sensitivity: 220mV✔ Efficiency: Up to 85% (varies by impedance)✔ Input Impedance: 15K Ohms✔ Output Impedance: 1, 2, or 4 Ohms (depending on version)✔ Bass Boost: 0 – 10dB @ 50Hz (adjustable 35 – 55Hz)✔ Power Supply Voltage: 9V – 16V DC✔ Standby Power Consumption: 1 – 1.5A✔ Max Music Power Consumption: 138 – 150A✔ Max Sinusoidal Power Consumption: 277 – 300A✔ Dimensions: 8.98" x 2.76" x 8.58" (228 x 70 x 218mm)✔ Weight: 5.5 lbs (2.5kg) What's Included? ✔ 1x Taramps MD 3000.1 Amplifier✔ 1x User Manual Reliability & Performance The Taramps MD 3000.1 is a powerhouse amplifier with cutting-edge technology, ensuring high power delivery with efficiency and safety. Whether you’re driving subwoofers, mid-bass, or full-range speakers, this amplifier guarantees crystal-clear sound with deep, impactful bass.

Read more less

Description The Taramps MD 5000.1 in the 1,2-ohm version has been carefully designed with the highest technology, offering high efficiency and performance for various types of car audio systems. This amplifier covers the whole frequency range, that is to say that it is a FULL RANGE (10Hz ~10 KHz (-3dB) module. It is classified as mono and has a channel with a maximum power of 5000-Watts RMS. Welcome to Taramps audio world. TECHNICAL INFORMATION OPERATION CLASS D NUMBER OF CHANNELS 01 MAXIMUM POWER @ 12.6 VDC - 1 OHM: 5000W RMS@ 12.6 VDC - 2 OHMS: 3200W RMS INPUT SENSITIVITY 220mV SIGNAL TO NOISE RATIO >90dB FREQUENCY RESPONSE 10Hz ~ 10KHz (-3dB) CROSSOVER HIGH PASS (HPF) 10Hz ~ 90Hz (-12dB/8ª) Variable CROSSOVER LOW PASS (LPF) 90Hz ~ 10KHz (-12dB/8ª) Variable BASS BOOST 35Hz ~ 55Hz0 ~ 10dB (50Hz) EFFICIENCY 81% INPUT IMPEDANCE 15K Ohms OUTPUT IMPEDANCE 1 Ohm PROTECTION SYSTEM Short-Circuit to output, short on output compared to GND, low impedance at output, High/Low supply voltage and thermal protection MIN. SUPPLY VOLTAGE 9VDC MAXIMUM POWER SUPPLY VOLTAGE 16VDC CONSUMPTION AT REST 1.20A MAXIMUM MUSIC CONSUMPTION 244.50A MAXIMUM CONSUMPTION IN SINUSOIDAL SIGNAL 489A DIMENSIONS (WXHXD) 8.98" x 2.76" x 12.87" (228 x 70 x 327mm) WEIGHT 9.28lb (4,22kg) EAN 7898556844697 TECHNICAL INFORMATION OPERATION CLASS Class D NUMBER OF CHANNELS 01 MAXIMUM POWER @ 12.6 VDC - 2 OHMS: 5000W RMS@ 12.6 VDC - 4 OHMS: 3200W RMS INPUT SENSITIVITY 220 mV SIGNAL TO NOISE RATIO >90dB FREQUENCY RESPONSE 10Hz ~ 10KHz (-3dB) CROSSOVER HIGH PASS (HPF) 10Hz ~ 90Hz (-12dB/8ª) Variable CROSSOVER LOW PASS (LPF) 90Hz ~ 10KHz (-12dB/8ª) Variable BASS BOOST 0 ~ 10dB (50Hz) Variable Frequency (35 ~ 55) EFFICIENCY 86% INPUT IMPEDANCE 15K Ohms OUTPUT IMPEDANCE 02 OHMS PROTECTION SYSTEM Short-Circuit to Output, Short on output compared to GND, Low impedance at output, low/high supply voltage and Thermal protection. MIN. SUPPLY VOLTAGE 9VDC MAXIMUM POWER SUPPLY VOLTAGE 16VDC CONSUMPTION AT REST 1.40 A MAXIMUM MUSIC CONSUMPTION 230.5 A MAXIMUM CONSUMPTION IN SINUSOIDAL SIGNAL 461 A DIMENSIONS (WXHXD) 8.98" x 2.76" x 12.87" (228 x 70 x 327mm ) WEIGHT 9.28lb (422kg) EAN 7898556844499

Read more less

Description The Taramps MD 250.1 in the 4, 2-ohm version has been carefully designed with the highest technology, offering high efficiency and performance for various types of car audio systems. This amplifier covers the entire frequency range, that is, it is a FULL RANGE module. It is classified as mono and has a channel with a maximum power of 250-Watts RMS. Welcome to Taramps audio world. TECHNICAL INFORMATION OPERATION CLASS Class D NUMBER OF CHANNELS 01 MAXIMUM POWER @ 13.8 VDC - 2 OHMS: 250W RMS@ 13.8 VDC - 4 OHMS: 160W RMS INPUT SENSITIVITY 220mV SIGNAL TO NOISE RATIO >90dB FREQUENCY RESPONSE 10Hz ~ 20KHz (-3dB) CROSSOVER HIGH PASS (HPF) 10Hz ~ 80Hz (-12dB/8ª) Variable CROSSOVER LOW PASS (LPF) 80Hz ~ Full (-12dB/8ª) Variable BASS BOOST 0 ~ 10dB (50Hz) INPUT IMPEDANCE 10K ohms OUTPUT IMPEDANCE 2 ohms PROTECTION SYSTEM Output short-circuit / thermal protection MIN. SUPPLY VOLTAGE 9 VDC MAXIMUM POWER SUPPLY VOLTAGE 16VDC CONSUMPTION AT REST 0.5 A MAXIMUM MUSIC CONSUMPTION 12.5 A MAXIMUM CONSUMPTION IN SINUSOIDAL SIGNAL 25 A DIMENSIONS (WXHXD) 5.43" x 1.92" x 5.19" (138 x 49 x 132mm) WEIGHT 1.43lb (0,65kg) EAN 7898556845090   TECHNICAL INFORMATION OPERATION CLASS Class D NUMBER OF CHANNELS 01 MAXIMUM POWER @ 13.8 VDC - 2 OHMS: 250W RMS@ 13.8 VDC - 4 OHMS: 160W RMS INPUT SENSITIVITY 220mV SIGNAL TO NOISE RATIO >90dB FREQUENCY RESPONSE 10Hz ~ 20KHz (-3dB) CROSSOVER HIGH PASS (HPF) 10Hz ~ 80Hz (-12dB/8ª) Variable CROSSOVER LOW PASS (LPF) 80Hz ~ Full (-12dB/8ª) Variable BASS BOOST 0 ~ 10dB (50Hz) INPUT IMPEDANCE 10K ohms OUTPUT IMPEDANCE 4 ohms PROTECTION SYSTEM Short-circuit and thermal protection MIN. SUPPLY VOLTAGE 9 VDC MAXIMUM POWER SUPPLY VOLTAGE 16VDC CONSUMPTION AT REST 0.55 A MAXIMUM MUSIC CONSUMPTION 12 A MAXIMUM CONSUMPTION IN SINUSOIDAL SIGNAL 24 A DIMENSIONS (WXHXD) 5.43" x 1.92" x 5.19" (138 x 49 x 132mm) WEIGHT 1.43lb (0,65kg) EAN 7898556845106

Read more less

Taramps presents the MD 8000.1 amplifier module in the 1,2 ohms version. It was carefully developed with the highest technology, offering high performance and performance for the most varied automotive sound systems, meeting the entire frequency range, in other words, it is a FULL RANGE module (10Hz ~10KHz(-3dB). amplifier classified as mono, has a channel with maximum power of 8000 Watts RMS. Welcome to the sound world of Taramps. TECHNICAL INFORMATIONOPERATION CLASS Class DNUMBER OF CHANNELS 01MAXIMUM POWER @ 12.6 VDC - 1 OHM: 8000W RMS@ 12.6 VDC - 2 OHMS: 5120W RMSINPUT SENSITIVITY 220mVSIGNAL/NOISE RATIO >90dBFREQUENCY RESPONSE 10Hz ~10KHz(-3dB)CROSSOVER HIGH PASS (HPF) 10Hz ~90Hz(-12dB/8th) VariableCROSSOVER LOW PASS (LPF) 90Hz ~10KHz(-12dB/8th) VariableBASS BOOST Freq.: 35Hz ~55HzBoost: 0~10dB(50Hz)EFFICIENCY 85%INPUT IMPEDANCE 22K OHMSOUTPUT IMPEDANCE 1 OhmPROTECTION SYSTEM Output Short, Output Short to GND, Low Impedance Protection, High/Low Voltage Protection and Thermal Protection.9VDC MINIMUM SUPPLY VOLTAGEMAXIMUM SUPPLY VOLTAGE 16VDCCONSUMPTION AT REST 2AMAXIMUM MUSIC CONSUMPTION 373.40AMAXIMUM CONSUMPTION IN SINUSUAL SIGNAL 746.90aDIMENSIONS (LXAXP) 228 x 70 x 419mmWEIGHT 6.10KgEAN 7898556844468TECHNICAL INFORMATIONOPERATION CLASS Class DNUMBER OF CHANNELS 01MAXIMUM POWER @ 12.6 VDC - 2 OHMS: 8000W RMS@ 12.6 VDC - 4 OHMS: 5120W RMSINPUT SENSITIVITY 220mVSIGNAL/NOISE RATIO >90dBFREQUENCY RESPONSE 10Hz ~10KHz(-3dB)CROSSOVER HIGH PASS (HPF) 10Hz ~90Hz(-12dB/8th) VariableCROSSOVER LOW PASS (LPF) 90Hz ~10KHz(-12dB/8th) VariableBASS BOOST Freq.: 35Hz ~55HzBoost: 0~10dB(50Hz)EFFICIENCY 87%INPUT IMPEDANCE 22K OHMSOUTPUT IMPEDANCE 2 OHMSPROTECTION SYSTEM Output Short, Output Short to GND, Low Impedance Protection, High/Low Voltage Protection and Thermal Protection9VDC MINIMUM SUPPLY VOLTAGEMAXIMUM SUPPLY VOLTAGE 16VDCCONSUMPTION AT REST 2.5AMAXIMUM MUSIC CONSUMPTION 364.90AMAXIMUM CONSUMPTION IN SINUSUAL SIGNAL 729.80ADIMENSIONS (LXAXP) 228 x 70 x 419mmWEIGHT 6.10KgEAN 7898556844406

Read more less

Description Aiming at strength and safety in a single product, Taramps designed the PRO CHARGER 30A. With a power of up to 30 amps, it is the most modern power converter for high-power batteries, and it efficiently recharges batteries or powers a car audio system. With output short circuit protection and current control, it is automatic bi-volt and has a fixed output voltage of 14.4VDC. The PRO CHARGER 30A has the best cost-benefit in the car audio sound industry. TECHNICAL INFORMATION AC INPUT VOLTAGE Bivolt Automatic (127 / 220VAC) AC INPUT VOLTAGE 127V 100~140V AC AC INPUT VOLTAGE 220V 190~240V AC MAXIMUM OUTPUT CURRENT 30A MAXIMUM OUTPUT POWER RATING 430W EFFICIENCY 90% MAXIMUM INPUT CURRENT 127V 5.6A MAXIMUM INPUT CURRENT 220V 4.0A MAXIMUM FLOAT 30A @14.2V: <8% INTERNAL FUSE 10A OUTPUT VOLTAGE 14.4V ± 2% DIMENSIONS (WXHXD) 6.54" x 2" x 5.71" (166 x 51 x 145 mm) WEIGHT 2.35 lbs (1,07 Kg) EAN 7898556844864

Read more less

Description Introducing the Pro Charger 40A. This bivolt battery charger and source (127/220V AC) has variable voltage adjustment (12V DC to 14.4V DC) and full charge indicator.Capable of supplying up to 40 Amperes, it can be used as: Battery charger, power supply, auxiliary for automotive sound systems, among others. TECHNICAL INFORMATION FOOD Automatic Bivolt (127/220VAC) NETWORK VOLTAGE RANGE 127V 100 ~ 140V AC NETWORK VOLTAGE RANGE 220V 200 ~ 240V AC RATED CURRENT MAX. ABOUT TO LEAVE 40A MAXIMUM OUTPUT POWER 560W EFFICIENCY 90% CONSUMPTION MAX. IN 127V NETWORK 11A CONSUMPTION MAX. IN 220V NETWORK 09A MAXIMUM FLOAT AT FULL LOAD <5% INPUT FUSE (INTERNAL) 10A OUTPUT VOLTAGE 12V ~ 14.4V ± 2% DIMENSIONS (WXHXD) 182 x 52 x 170mm WEIGHT 1.20 kg EAN 7898556848145

Read more less

Description The PRO Charger 60A is a power supply and/or battery charger with current up to 60 Amps. With advanced and innovative technology for high power energy converters for battery recharging and car audio systems. Automatic bi-voltage, the PRO Charger 60A has adjustable output voltage from 12.4 to 14.5VDC, voltmeter, short circuit protection and current control. Safety and strength to make your car audio system complete. TECHNICAL INFORMATION AC INPUT VOLTAGE Bivolt Automatic (127/220V AC) AC INPUT VOLTAGE 127V 90~140V AC AC INPUT VOLTAGE 220V 190~240V AC MAXIMUM OUTPUT CURRENT 60A MAXIMUM OUTPUT POWER RATING 860W EFFICIENCY 90% MAXIMUM INPUT CURRENT 127V 11A MAXIMUM INPUT CURRENT 220V 09A MAXIMUM FLOAT 60A @14.2V: <5% INTERNAL FUSE 10A OUTPUT VOLTAGE 12.4V ~ 14.5V ± 2% DIMENSIONS (WXHXD) 7.16" x 2" x 8.86" (182 x 51 x 225mm) WEIGHT 3.98lb (1,81Kg) EAN 7898556844543

Read more less

Description The Pro 2.4S is a 4-channel digital audio processor. Designed with the highest technology, it offers vital features and adjustments for car audio, such as: crossover with multiple filters, 15-band graphic equalization, 12 pre-defined equalizations, parametric equalization, alignment, routing, phase inversion, limiter, input and output clip indicator, remote signal output to activate amplifiers, audio generator, among many others. In addition, it features an audio input via RCA and also a high level input, allowing use with conventional and original head units (eg multimedia without RCA output). Another advantage of this product is the anti-puff system, which prevents those infamous pops when turning the sound on and off. All this and much more to keep your sound system always tuned, aligned and with the quality you deserve. TECHNICAL INFORMATION INPUT IMPEDANCE 10K Ohms (RCA)50 Ohms (HIGH LEVEL) OUTPUT IMPEDANCE 47 Ohms MAXIMUM INPUT LEVEL 5,9Vpp 2,1V RMS (RCA)28Vpp 10V RMS (HIGH LEVEL) MAXIMUM OUTPUT LEVEL 5.9Vpp 2.1V RMS FREQUENCY RESPONSE 10Hz to 22KHz TOTAL HARMONIC DISTORTION 0.01% SIGNAL TO NOISE RATIO >90dB CROSSTALK (SEPARATION BETWEEN CHANNELS) >80dB POWER SUPPLY VOLTAGE 10 to 16VDC INPUT CHANNELS 2 OUTPUT CHANNELS 4 ROUTING A,B,A+B GENERAL GAIN -80 to 0dB OUTPUT GAIN -45 a +15dB CROSSOVER HPF (Variable): Variable FiltersLPF (Variable): Variable Filters LINKWITZ RILLEY FILTERS -12,-18,-24,-36,-48dB/Octave BUTTERWORTH FILTERS -6,-12,-18,-24,-36,-48dB/Octave ALIGNMENT 8,0 mS (272cm) PHASE 0 / 180º LANGUAGES Portuguese, English and Spanish MEMORY POSITIONS Factory default + 3 assignable positions DIMENSIONS (WXHXD) 7.79" x 1.42" x 4.44" (198 x 36 x 113mm) WEIGHT 0.99lb (0,450 Kg) EAN 7898556847919

Read more less

Description Always dedicated to improving your experience with your car audio system, Taramps innovated again by producing the PRO2.6S audio processor.  DSP, 2 independent inputs and 6 outputs, it has features such as routing, crossover filters, delay adjustment, alignment, phase inversion, adjustable limiter, parametric equalizer on outputs, mirroring, mute, sinusoidal wave generator and memory for settings . Taramps, always working to make your audio system more complete and easier to handle. TECHNICAL INFORMATION INPUT IMPEDANCE 18k ohms OUTPUT IMPEDANCE 47 ohms MAXIMUM INPUT LEVEL 6Vpp (2.1V RMS) MAXIMUM OUTPUT LEVEL 10.2Vpp (3.6V RMS) FREQUENCY RESPONSE 10 Hz ~ 20 kHz SIGNAL TO NOISE RATIO >90dB CROSSTALK (SEPARATION BETWEEN CHANNELS) >80dB POWER SUPPLY VOLTAGE 9 ~ 16VDC INPUT CHANNELS 02 OUTPUT CHANNELS 06 ROUTING A,B,A+B GENERAL GAIN 80 ~ 0dB OUTPUT GAIN 24 ~ +6dB CROSSOVER HPF (Variable): Variable FiltersLPF (Variable): Variable Filters ALIGNMENT 5.7 mS - 76.38" (194cm) PHASE 0 / 180º THRESHOLD 24 ~ 0dB ATTACK 1ms ~ 900ms RELEASE 1ms ~ 4000ms PARAMETRIC EQUALIZER (3 BANDS) PER OUTPUT Central Frequency: 20Hz ~ 20KHzAttenuation - Gain: -12dB ~ +12dBQ Factor: 0.4 ~ 10 FREQUENCY RANGE 20 Hz ~ 20 kHz GAIN -60 ~ 0dB LANGUAGES Portuguese - English - Spanish MEMORY POSITIONS 3 + factory default DIMENSIONS (WXHXD) 8.27" x 1.7" x 4.80" (210 x 43 x 122 mm) WEIGHT 1.21 lbs (0.550 kg) EAN 7898556844093 ADDITIONAL INFORMATION Limiter AdjustableOutput mirroring functionIndividual MUTE Function on outputsAudio Generator

Read more less
