The ELECTRA line was developed especially for those looking for incomparable bass. It has a frequency response of 5 to 500Hz (-3dBs). Due to this, the ELECTRA will only play Subwoofers , Bass and part of the mid frequencies. The BASS BOOST @ 45Hz feature is a differentiator, further reinforcing the bass of your system. Designed on a 100% aluminum chassis , it works with a power of 3000 WRMS with 1 input channel for connection and an impedance of 1 Ohm. It has very low harmonic distortion (less than 1%) and Clipping indicator, forced ventilation and short circuit protection. Furthermore, it has a bold and clean design, matching any sound system. Technical specifications Maximum Power 14.4v @ 1 Ohm 3600 WRMS Maximum Power 14.4v @ 2 Ohms 2400WRMS Maximum Power 12.6v @ 1 Ohm 3000 WRMS Maximum Power 12.6v @ 2 Ohms 1800 WRMS Efficiency @ 2 Ohms 82% Efficiency @ 1 Ohm 75% Input Voltage 9 – 15V Input Impedance 100K Ohms THD+N 0.10% Input Sensitivity 110mV – 8V Signal to Noise Ratio 82dB Frequency Response (Switch OFF) 5 to 500Hz (-3dBs) Frequency Response 20 to 500Hz (-3dBs) Bass Boost @ 45Hz Variable 0 to +18dBs HPF (Subsonic) 20 to 80Hz @ 12dB/octave Linkwitz-Riley LPF (Crossover) 80 to 500Hz @ 12dB/octave Linkwitz-Riley Recommended Fuse 150 A Rest Current 2A Maximum Current (sine signal) 320A Maximum Current (musical signal) 160A Power Cables (recommended min.) 21mm / 4 AWG Output Cables (recommended min.) 2 x 4mm / 2 x 11 AWG Weight (kg) 4.9 Height (mm) 60 Width (mm) 264 Depth (mm) 308

Read more less

The ELECTRA line was developed especially for those looking for incomparable bass. It has a frequency response of 5 to 500Hz (-3dBs). Due to this, the ELECTRA will only play Subwoofers , Bass and part of the mid frequencies. The BASS BOOST @ 45Hz feature is a differentiator, further reinforcing the bass of your system. Designed on a 100% aluminum chassis , it works with a power of 3000 WRMS with 1 input channel for connection and an impedance of 2 Ohms. It has very low harmonic distortion (less than 1%) and Clipping indicator, forced ventilation and short circuit protection. Furthermore, it has a bold and clean design, matching any sound system. Technical specifications Maximum Power 14.4v @ 2 Ohms 3700 WRMS Maximum Power 14.4v @ 4 Ohms 2300 WRMS Maximum Power 12.6v @ 2 Ohms 3000 WRMS Maximum Power 12.6v @ 4 Ohms 1700 WRMS Efficiency @ 4 Ohms 84% Efficiency @ 2 Ohms 80% Input Voltage 9 – 15V Input Impedance 100K Ohms THD+N 0.10% Input Sensitivity 140mV – 8V Signal to Noise Ratio 86dB Frequency Response (Switch OFF) 5 to 500Hz (-3dBs) Frequency Response 20 to 500Hz (-3dBs) Bass Boost @ 45Hz Variable 0 to +18dBs HPF (Subsonic) 20 to 80Hz @ 12dB/octave Linkwitz-Riley LPF (Crossover) 80 to 500Hz @ 12dB/octave Linkwitz-Riley Recommended Fuse 150 A Rest Current 2A Maximum Current (sine signal) 315A Maximum Current (musical signal) 155A Power Cables (recommended min.) 21mm / 4 AWG Output Cables (recommended min.) 2 x 4mm / 2 x 11 AWG Weight (kg) 4.9 Height (mm) 60 Width (mm) 264 Depth (mm) 308

Read more less

The ELECTRA line was developed especially for those looking for incomparable bass. It has a frequency response of 5 to 500Hz (-3dBs). Due to this, the ELECTRA will only play Subwoofers , Bass and part of the mid frequencies. The BASS BOOST @ 45Hz feature is a differentiator, further reinforcing the bass of your system. Designed on a 100% aluminum chassis , it works with a power of 3000 WRMS with 1 input channel for connection and an impedance of 4 Ohms. It has very low harmonic distortion (less than 1%) and Clipping indicator, forced ventilation and short circuit protection. Furthermore, it has a bold and clean design, matching any sound system. Technical specifications Maximum Power 14.4v @ 4 Ohms 3700 WRMS Maximum Power 14.4v @ 8 Ohms 2200WRMS Maximum Power 12.6v @ 4 Ohms 3000 WRMS Maximum Power 12.6v @ 8 Ohms 1700 WRMS Efficiency @ 8 Ohms 92% Efficiency @ 4 Ohms 86% Input Voltage 9 – 15V Input Impedance 100K Ohms THD+N 0.10% Input Sensitivity 150mV – 8V Signal to Noise Ratio 80dB Frequency Response (Switch OFF) 5 to 500Hz (-3dBs) Frequency Response 20 to 500Hz (-3dBs) Bass Boost @ 45Hz Variable 0 to +18dBs HPF (Subsonic) 20 to 80Hz @ 12dB/octave Linkwitz-Riley LPF (Crossover) 80 to 500Hz @ 12dB/octave Linkwitz-Riley Recommended Fuse 150 A Rest Current 2A Maximum Current (sine signal) 300 A Maximum Current (musical signal) 150 A Power Cables (recommended min.) 21mm / 4 AWG Output Cables (recommended min.) 2 x 2.5mm / 2 x 13 AWG Weight (kg) 4.9 Height (mm) 60 Width (mm) 264 Depth (mm) 308

Read more less

The ELECTRA line was developed especially for those looking for incomparable bass. It has a frequency response of 5 to 500Hz (-3dBs). Due to this, the ELECTRA will only play Subwoofers , Bass and part of the mid frequencies. The BASS BOOST @ 45Hz feature is a differentiator, further reinforcing the bass of your system. Designed on a 100% aluminum chassis , it works with a power of 5000 WRMS with 1 input channel for connection and an impedance of 1 Ohm. It has very low harmonic distortion (less than 1%) and Clipping indicator, forced ventilation and short circuit protection. Furthermore, it has a bold and clean design, matching any sound system. ELECTRA 5K1 Technical specifications Maximum Power 14.4v @ 1 Ohm 6200WRMS Maximum Power 14.4v @ 2 Ohms 4300WRMS Maximum Power 12.6v @ 1 Ohm 5000WRMS Maximum Power 12.6v @ 2 Ohms 3600 WRMS Efficiency @ 2 Ohms 77% Efficiency @ 1 Ohm 67% Input Voltage 9 – 15V Input Impedance 100K Ohms THD+N 0.10% Input Sensitivity 40mV – 2V Signal to Noise Ratio 90dB Frequency Response (Switch OFF) 5 to 500Hz (-3dBs) Frequency Response 20 to 500Hz (-3dBs) Bass Boost @ 45Hz Variable 0 to +18dBs HPF (Subsonic) 20 to 80Hz @ 12dB/octave Linkwitz-Riley LPF (Crossover) 80 to 500Hz @ 12dB/octave Linkwitz-Riley Recommended Fuse 250 A Rest Current 3.5A Maximum Current (sine signal) 600A Maximum Current (musical signal) 270A Power Cables (recommended min.) 50mm / 0 AWG Output Cables (recommended min.) 2 x 6mm / 2 x 3 AWG Weight (kg) 5.4 Height (mm) 60 Width (mm) 264 Depth (mm) 308

Read more less

The ELECTRA line was developed especially for those looking for incomparable bass. It has a frequency response of 5 to 500Hz (-3dBs). Due to this, the ELECTRA will only play Subwoofers , Bass and part of the mid frequencies. The BASS BOOST @ 45Hz feature is a differentiator, further reinforcing the bass of your system. Designed on a 100% aluminum chassis , it works with a power of 5000 WRMS with 1 input channel for connection and an impedance of 2 Ohms. It has very low harmonic distortion (less than 1%) and Clipping indicator, forced ventilation and short circuit protection. Furthermore, it has a bold and clean design, matching any sound system. Technical specifications Maximum Power 14.4v @ 2 Ohms 5500WRMS Maximum Power 14.4v @ 4 Ohms 3600 WRMS Maximum Power 12.6v @ 2 Ohms 5000WRMS Maximum Power 12.6v @ 4 Ohms 3000 WRMS Efficiency @ 4 Ohms 83% Efficiency @ 2 Ohms 78% Input Voltage 9 – 15V Input Impedance 100K Ohms THD+N 0.10% Input Sensitivity 50mV – 2V Signal to Noise Ratio 93dB Frequency Response (Switch OFF) 5 to 500Hz (-3dBs) Frequency Response 20 to 500Hz (-3dBs) Bass Boost @ 45Hz Variable 0 to +18dBs HPF (Subsonic) 20 to 80Hz @ 12dB/octave Linkwitz-Riley LPF (Crossover) 80 to 500Hz @ 12dB/octave Linkwitz-Riley Recommended Fuse 250 A Rest Current 3.5A Maximum Current (sine signal) 500A Maximum Current (musical signal) 270A Power Cables (recommended min.) 50mm / 0 AWG Output Cables (recommended min.) 2 x 6mm / 2 x 3 AWG Weight (kg) 5.4 Height (mm) 60 Width (mm) 264 Depth (mm) 308

Read more less

Banda Electra Bass 8K Amplifier Module Power 1 Ohm - 8000 Watts RMS The ELECTRA line has been meticulously crafted for those in pursuit of unmatched, deep bass. It boasts a frequency response spanning from 16 to 500Hz, making it ideal for driving subwoofers and bass with precision. The standout feature is the variable BASS BOOST, adjustable from 30 to 80Hz with an impressive 12dB boost capability, enhancing the low-end performance of your audio system. Key Highlights: Impressive Frequency Response: With a wide frequency response range from 16 to 500Hz, the ELECTRA is perfectly suited for driving subwoofers and bass. It excels in delivering deep, resonant low-frequency tones that bring your audio to life. Variable BASS BOOST: The adjustable BASS BOOST, with a range of 30 to 80Hz and a powerful 12dB boost, allows you to fine-tune your bass to perfection, delivering a powerful and immersive listening experience. Robust Aluminum Construction: Housed in a robust 100% aluminum chassis, the ELECTRA is built to last and efficiently dissipates heat to ensure consistent performance, even during intense use. Impedance and Power: This amplifier is capable of producing 8000 Watts RMS with a 1-ohm impedance, providing the necessary power for impactful bass reproduction. Additional Technical Specifications: Maximum Power at 14.4V @ 1 Ohm: 9000 Watts RMS Maximum Power at 14.4V @ 2 Ohms: 7400 Watts RMS Maximum Power at 12.6V @ 1 Ohm: 8000 Watts RMS Maximum Power at 12.6V @ 2 Ohms: 5100 Watts RMS Efficiency @ 2 Ohms: 83% Efficiency @ 1 Ohm: 77% Input Voltage: 9 - 15V Input Impedance: 100K Ohms Maximum THD at Full Power: <3% Input Sensitivity: 200mV to 8V Signal-to-Noise Ratio: 80dB Frequency Response: 16 to 500Hz (-3dB) High-Pass Filter (Subsonic): 16 - 120Hz @ 12dB/octave Linkwitz-Riley Low-Pass Crossover (LPF): 50 - 500Hz @ 12dB/octave Linkwitz-Riley Variable Bass Boost: 30 - 80Hz with up to 12dB boost Recommended Fuse: 2 x 225A Standby Current Draw: ~3A Maximum Current Draw (Musical Signal): 400A Maximum Current Draw (Sine Signal): 850A Minimum Recommended Power Cable: 70mm / 0 AWG Minimum Recommended Output Cable: 2 x 6mm / 2 x 3 AWG Weight (Kg): 6.3 Height (mm): 73 Width (mm): 256 Depth (mm): 317 The ELECTRA 8K 1 Ohm Amplifier Module is the ultimate choice for those who demand exceptional bass performance and precision. Elevate your audio experience to new heights with this powerful and versatile amplifier.

Read more less

Banda Electra Bass 8K Amplifier Audio Car 8000 Watts RMS 2 ohms The ELECTRA line has been meticulously engineered for those in pursuit of unparalleled bass performance. With a frequency response spanning from 16 to 500Hz, the ELECTRA is designed specifically for subwoofers and bass. The distinguishing feature is the variable BASS BOOST, adjustable from 30 to 80Hz with an impressive 12dB boost capability, enhancing the bass response of your audio system. Key Features: Wide Frequency Response: With a wide frequency response range from 16 to 500Hz, the ELECTRA is perfectly suited for driving subwoofers and bass. It excels in delivering deep, resonant low-frequency tones, immersing you in powerful and immersive sound. Variable BASS BOOST: The adaptable BASS BOOST feature, adjustable between 30 and 80Hz with a powerful 12dB boost, allows you to customize your bass to perfection, delivering a dynamic and impactful listening experience. Robust Aluminum Construction: Housed in a sturdy 100% aluminum chassis, the ELECTRA is built to last and efficiently dissipates heat to ensure consistent performance, even under intense use. Impedance and Power: This amplifier is capable of producing 8000 Watts RMS with a 2-ohm impedance, providing the necessary power for precise bass reproduction. Additional Technical Specifications: Maximum Power at 14.4V @ 2 Ohms: 9500 Watts RMS Maximum Power at 14.4V @ 4 Ohms: 6800 Watts RMS Maximum Power at 12.6V @ 2 Ohms: 8000 Watts RMS Maximum Power at 12.6V @ 4 Ohms: 5100 Watts RMS Efficiency @ 4 Ohms: 88% Efficiency @ 2 Ohms: 79% Input Voltage: 9 - 15V Input Impedance: 100K Ohms Maximum THD at Full Power: <3% Input Sensitivity: 200mV to 8V Signal-to-Noise Ratio: 80dB Frequency Response: 16 to 500Hz (-3dB) High-Pass Filter (Subsonic): 16 - 120Hz @ 12dB/octave Linkwitz-Riley Low-Pass Crossover (LPF): 50 - 500Hz @ 12dB/octave Linkwitz-Riley Variable Bass Boost: 30 - 80Hz with up to 12dB boost Recommended Fuse: 2 x 225A Standby Current Draw: ~3A Maximum Current Draw (Musical Signal): 400A Maximum Current Draw (Sine Signal): 850A Minimum Recommended Power Cable: 70mm / 0 AWG Minimum Recommended Output Cable: 2 x 6mm / 2 x 3 AWG Weight (Kg): 6.3 Height (mm): 73 Width (mm): 256 Depth (mm): 317 The ELECTRA 8K 2 Ohms Amplifier Module is the perfect choice for those who demand exceptional bass performance and precision. Elevate your audio experience to new heights with this powerful and versatile amplifier.

Read more less

With a powerful 2000 Watts RMS in 4 channels and impedance of 1 or 2 Ohms per channel, the amplifiers of the new ELITE line are very versatile, allowing different types of installation with a single amplifier. Thanks to its FULL-RANGE frequency response range, the ELITE fits into any project with: Subwoofers, Woofers, Low-Mid, Horns or Super Tweeters, and it is also possible to make 4, 3 or 2 channel calls when used. on Bridge connections. With the ELITE 2000.4 it is possible to connect a complete medium-sized sound system, enjoying the audio quality already established by BAND AUDIOPARTS in addition to low consumption. Class D Total Power 14,4 @ 2 Ohms 4 x 600 WRMS Total Power 14,4 @ 4 Ohms 4 x 400 WRMS Total Power 14,4 Bridged @ 4 Ohms 2 x 1250 WRMS Total Power 12,6 @ 2 Ohms 4 x 500 WRMS Total Power 12,6 @ 4 Ohms 4 x 300 WRMS Total Power 12,6 Bridged @ 4 Ohms 2 x 1000 WRMS Efficiency @ 4 Ohms 86% Efficiency @ 2 Ohms 80% Input Voltage 9 – 15V Input Impedance 100K Ohms THD+Noise <1% Input Sensitivity 220mV – 4V SNR 80dB Frequency Response 5 to 22kHz (-3dBs) HPF (High Pass Filter) 20 to 90Hz @ 12dB/octave Linkwitz-Riley LPF (Low Pass Filter) 90 to 20kHz @ 12dB/octave Linkwitz-Riley Recommended Fuse 100 A Current at Rest 1 A Average Current Draw (Sinusoidal) 210 A Average Current Draw (Music) 100 A Power Wire Gauge (min. Recommended) 21mm / 4 AWG Speaker Wire Gauge (min. Recommended) 2 x 2,5mm / 2 x 13 AWG Weight (Lb) 7,2 Height (in) 2,2 Width (in) 8,4 Depth (in) 9,7

Read more less

With a powerful 4000 Watts RMS in 4 channels and impedance of 1 or 2 Ohms per channel, the amplifiers of the new ELITE line are very versatile, allowing different types of installation with a single amplifier. Thanks to its FULL-RANGE frequency response range, the ELITE fits into any project with: Subwoofers, Woofers, Low-Mid, Horns or Super Tweeters, and it is also possible to make 4, 3 or 2 channel calls when used. on Bridge connections. With the ELITE 4000.4 it is possible to connect a complete medium-sized sound system, enjoying the audio quality already established by BAND AUDIOPARTS in addition to low consumption. Class D Total Power 14,4 @ 2 Ohms 4 x 1200 WRMS Total Power 14,4 @ 4 Ohms 4 x 800 WRMS Total Power 14,4 Bridged @ 4 Ohms 2 x 2400 WRMS Total Power 12,6 @ 2 Ohms 4 x 1000 WRMS Total Power 12,6 @ 4 Ohms 4 x 650 WRMS Total Power 12,6 Bridged @ 4 Ohms 2 x 2000 WRMS Efficiency @ 4 Ohms 92% Efficiency @ 2 Ohms 82% Input Voltage 9 – 15V Input Impedance 100K Ohms THD+Noise 0,10% Input Sensitivity 150mV – 4V SNR 88dB Frequency Response 5 to 22KHz (-3dBs) HPF (High Pass Filter) 20 to 90Hz @ 12dB/octave Linkwitz-Riley LPF (Low Pass Filter) 90 to 20kHz @ 12dB/octave Linkwitz-Riley Recommended Fuse 200 A Current at Rest 1 A Average Current Draw (Sinusoidal) 420 A Average Current Draw (Music) 210 A Power Wire Gauge (min. Recommended) 35mm / 2 AWG Speaker Wire Gauge (min. Recommended) 2 x 4mm / 2 x 11 AWG Weight (Lb) 11,2 Height (in) 2,4 Width (in) 10,6 Depth (in) 12,3

Read more less

Elite 800.4 - Power and Versatility in a Compact Design The Elite 800.4 amplifier delivers a robust 800Wrms across 4 channels, providing 200Wrms at 2 Ohms each or 400Wrms at 4 Ohms in Bridge mode. Designed for versatility, this line is a popular choice for small and medium-sized systems, accommodating various installation configurations to meet the diverse needs of the market and amplify any type of speaker. Technical Specifications: Maximum Power 14.4v @ 2 Ohms: 4 x 250 WRMS Maximum Power 14.4v @ 4 Ohms: 4 x 170 WRMS Maximum Power 14.4v Bridge @ 4 Ohms: 2 x 500 WRMS Efficiency @ 4 Ohms: 84% Efficiency @ 2 Ohms: 78% Input Voltage: 9 - 15V Input Impedance: 22K Ohms THD+N: 0.10% Input Sensitivity: 280mV - 4V Signal to Noise Ratio: 88dB Frequency Response: 5 to 22kHz (-3dBs) HPF (High Pass Filter): 20 to 90Hz @ 12dBs/8° Linkwitz-Riley LPF (Low Pass Filter): 90 to 20kHz @ 12dBs/8° Linkwitz-Riley Recommended fuse: 50 A Resting Current: 1 A Maximum Current (sine signal): 90 A Maximum Current (musical signal): 50 A Power Cables (recommended min): 10mm / 7 AWG Output Cables (recommended min): 2 x 1.5mm / 2 x 15 AWG Weight (Kg): 3.1 Height (mm): 54 Width (mm): 209 Depth (mm): 243 Comments: Warranty: 1 year provided by the manufacturer Illustrative Images: Merely for representation Installation: We strongly recommend professional installation. We are not responsible for poor installation or misuse of the product.

Read more less

Banda ICE 1500 Amplifier Module Power 1 Ohms 1500Wrms   DESCRIPTION  Especially developed for those who want power without loss of quality, Amplifier Modules are perfect devices for automotive sound projects, aiming at amplification and performance in audio reproduction.Designed by anyone who understands and invests in technology, the Ice 2500 amplifier module is one of the most efficient and modern modules in the Class D market, with 1500W RMS power, active Crossover by Linkwitz-Riley card, gain control and excellent signal-to-noise ratio, with LED clipping indicator, making it the most complete, modern and efficient equipment for automotive sound enthusiasts. CHARACTERISTICS1 channel 1500Wrms 2ohm / 12.6Vdc1 channel 1900Wrms 2ohm / 14.4Vdc1 channel 1000Wrms 4ohm / 12.6VdcFull Power Current: 79A (Average Music Program)Dimensions ICE 1500: Comp. 243mm / Hr. 54mm / Larg. 209mmWeight: 2.90kgDIMENSIONSDimensions: Comp. 243mm / Hr. 54mm / Larg. 209mm PACKAGE CONTENT• 1 - Band Amplifier 1 Channel ICE1500 - 1500W RMS (2 Ohms)  Important:1 year warranty.Auto Equip recommends that the installation be done by a specialized professional and does not take responsibility for the misuse of the product.

Read more less

Banda ICE 1500 Amplifier Module Power   2 Ohms 1500Wrms   DESCRIPTION  Especially developed for those who want power without loss of quality, Amplifier Modules are perfect devices for automotive sound projects, aiming at amplification and performance in audio reproduction.Designed by anyone who understands and invests in technology, the Ice 2500 amplifier module is one of the most efficient and modern modules in the Class D market, with 1500W RMS power, active Crossover by Linkwitz-Riley card, gain control and excellent signal-to-noise ratio, with LED clipping indicator, making it the most complete, modern and efficient equipment for automotive sound enthusiasts. CHARACTERISTICS1 channel 1500Wrms 2ohm / 12.6Vdc1 channel 1900Wrms 2ohm / 14.4Vdc1 channel 1000Wrms 4ohm / 12.6VdcFull Power Current: 79A (Average Music Program)Dimensions ICE 1500: Comp. 243mm / Hr. 54mm / Larg. 209mmWeight: 2.90kgDIMENSIONSDimensions: Comp. 243mm / Hr. 54mm / Larg. 209mm PACKAGE CONTENT• 1 - Band Amplifier 1 Channel ICE1500 - 1500W RMS (2 Ohms)  Important:1 year warranty.Auto Equip recommends that the installation be done by a specialized professional and does not take responsibility for the misuse of the product.

Read more less
