Description
EXPORT LINE STETSOM: An export-type product line that will please the world and Brazil.
Developed for those looking for high performance and sound fidelity in automotive amplifiers with the most innovative electronic components.
EXPORT LINE STETSOM. Performance to delight!
EX 13500 EQ features:
– EQ with three bands: BASS, MID BASS, MID HIGH, in addition to the traditional Level, High Pass and Low Pass features.
Bass EQ: -10dB to +10dB
Mid-Bass EQ: -10dB to +10dB
Mid-High EQ: -10dB to +10dB
– Frequency response from 10Hz to 10KHz and Cooler controlled by intelligent system.
TECHNICAL SPECIFICATIONS
| CHARACTERISTICS |
EX 13500 EQ – 1 OHM |
| Number of Channels |
1 |
| RMS Power at 1 Ohm 12.6V |
13500W RMS |
| RMS Power at 2 Ohm 12.6V |
9450W RMS |
| RMS Power at 4 Ohm 12.6V |
5400W RMS |
| RMS Power at 1 Ohm 14.4V |
14200W RMS |
| RMS Power at 2 Ohm 14.4V |
10100W RMS |
| RMS Power at 4 Ohm 14.4V |
6100W RMS |
| Supply Voltage |
9,5 ~ 15Vdc |
| Frequency Response |
10Hz ~10KHz |
| Crossover Low Pass |
50Hz ~10KHz |
| Crossover High Pass |
10Hz ~700Hz |
| Consumption with Signal Musical |
5,1A ~665A |
| Consumption with Signal Bass |
5,1A ~1330A |
| Dimensions (H x W x D) mm |
77 x 290 x 617 mm |
| Weight Kg |
9,6 Kg |
