The VIKING Line Viking 5000 is a high-performance Class D monoblock amplifier designed for powerful audio applications, particularly in medium to large car audio setups. Here’s a breakdown of its key features and specifications:
Key Features:
-
High Power Output: Delivers up to 5000W RMS @ 2Ω (12.6V) and 5500W RMS @ 2Ω (14.4V), making it ideal for subwoofers and high-power speaker setups.
-
Aluminum Chassis: Ensures efficient heat dissipation, improving performance and reducing battery drain.
-
Wide Frequency Response:
-
Adjustable Bass Boost: Variable 0 to +18dB @ 45Hz for deep bass enhancement.
-
Advanced Filtering:
-
HPF (Subsonic): 20Hz – 80Hz (12dB/octave)
-
LPF (Crossover): 80Hz – 5kHz (12dB/octave)
-
Both use Linkwitz-Riley slopes for precise tuning.
-
High Efficiency:
Electrical Specifications:
| Parameter |
Value |
| THD+Noise |
<1% |
| Input Sensitivity |
50mV – 2V |
| Signal-to-Noise Ratio (SNR) |
93dB |
| Input Impedance |
100kΩ |
| Recommended Fuse |
250A |
| Idle Current Draw |
3.5A |
| Avg. Current (Music) |
270A |
| Avg. Current (Sine Wave) |
500A |
Installation Requirements:
-
Power Wire: 0 AWG (50mm²) minimum
-
Speaker Wire: 2 x 3 AWG (2 x 6mm²) minimum
-
Voltage Range: 9V – 15V (stable operation even with slight voltage drops)
Physical Dimensions:
Ideal For:
-
Competition-grade subwoofer systems
-
Large SPL (Sound Pressure Level) builds
-
High-power bass applications
Conclusion:
The Viking 5000 is a beast of an amplifier, built for extreme power handling and efficient performance. Its adjustable filters, bass boost, and high efficiency make it a top choice for serious car audio enthusiasts and competitors. If you need massive bass with clean power, this amp delivers.
