Soundigital SD3000 EVO 5 Car Audio Amplifier 3000 Watts RMS

Descripción

The 3000.1 EVO 5 is an amplifier with a compact and modern design that delivers 3000W RMS of power in 1 channel.

The amplifier has exclusive and patented technologies that make the sound experience cleaner and more faithful, as well as ensuring better performance and efficiency for the most daring projects.

General Specifications

  • 3000.1 EVO 5 – 1 OHM

    Power @ 1Ω: 1 X 3000W RMS
    Power @ 2Ω: 1 X 1980W RMS
    Power @ 4Ω: 1 X 1307W RMS

  • 3000.1 EVO 5 – 2 OHMS

    Power @ 1Ω: N/A
    Power @ 2Ω: 1 X 3000W RMS
    Power @ 4Ω: 1 X 1980W RMS

  • Frequency Response (-3db): 5Hz ~ 25kHz

  • Subsonic Filter: 5Hz ~ 80Hz

  • Low Pass Filter: 50Hz ~ 1kHz

  • Bass Boost: 0dB ~ 12dB @ 50Hz

  • Power Voltage: 8V – 16V

  • Signal-Noise Ratio: 92dB

  • Input Sensitivity: 0.2V~2V

  • Music Consumption:

    1Ω: 149A
    2Ω: 139A
    4Ω: 140A

  • Consumption with Resistive Load:

    1Ω: 298A
    2Ω: 277A
    4Ω: 280A

  • Total Efficiency:

    1Ω: 80%
    2Ω: 86%
    4Ω: 85%

  • Damping Factor: >2000

  • Power cable: 35mm² (2AWG)

  • Audio Output Cable:

    1Ω: 2 x 4.0 mm² (11 AWG)
    2Ω: 2 x 2.5 mm² (13 AWG)
    4Ω: 2 x 1.5 mm² (15 AWG)

  • Fuse (Musical Use): 150A

  • Recommended Battery: 150Ah

  • Width: 13,6 cm

  • Length: 22,8 cm

  • Height: 5,48 cm

  • Weight: 1,75 Kg



    EVO 5 Line Differentials

    • Technologies:

      Line 5 products feature the latest in SounDigital audio solutions. Modern components, with high performance distributed in intelligent projects guarantee better performance, temperature management and a lot of quality and power.

    • Performance:

      Flatter and more extensive frequency responses, accurate tone, more accurate bass and treble are the best definition of the performance of SounDigital products. Product performance has been substantially improved due to new source concepts, output filters and audio processing circuitry.

    • Reliability:

      SounDigital's products are increasingly robust and reliable. State-of-the-art solutions make the temperature control and vibration resistance of the EVO5 range the best on the market.

    •

      SounDigital's products are increasingly robust and reliable. State-of-the-art solutions make the EVO5 range's temperature control and vibration resistance the best on the market.
      The protections have been modernized, and are more reliable and faster, that is, any failure in the power supply or a speaker connected to the amplifier will not cause any problems to the amplifier of the EVO5 line, as the intelligent protection systems will protect it.

    • Installation solutions:

      The products of the EVO5 line are designed to facilitate installation, they use massive connectors, with ALLEN steel screws that guarantee the best fixation for the wires, the screws that fix the product to the installation point are protected by removable covers, that guarantee a cleaner and more refined installation.

    •

      Some products in the line now have a high signal input with SSS, SounDigital Smart Start, a system that uses the conventional audio outputs of vehicle audio units and does not require the use of the remote trigger wire. These and other facilities help in a correct, well-finished and reliable installation of the product.
