DESCRIPTIONEXPORT LINE STETSOM: An export-type product line that will please the world and Brazil.Developed for those looking for high performance and sound fidelity in automotive amplifiers with the most innovative electronic components.EXPORT LINE STETSOM. Performance to delight!EX 3500 EQ features:– EQ with three bands: BASS, MID BASS, MID HIGH, in addition to the traditional Level, High Pass and Low Pass features.Bass EQ: -10dB to +10dBMid-Bass EQ: -10dB to +10dBMid-High EQ: -10dB to +10dB– Frequency response from 10Hz to 25KHz and Cooler controlled by intelligent system. TECHNICAL SPECIFICATIONS CHARACTERISTICS EX 3500 EQ – 1 OHM Number of Channels 1 RMS Power at 1 Ohm 12.6V 3500W RMS RMS Power at 2 Ohm 12.6V 2300W RMS RMS Power at 4 Ohm 12.6V 1300W RMS RMS Power at 1 Ohm 14.4V 4000W RMS RMS Power at 2 Ohm 14.4V 2600W RMS RMS Power at 4 Ohm 14.4V 1600W RMS Supply Voltage 9,5 ~ 15Vdc Frequency Response 10Hz ~ 25KHz Crossover Low Pass 50Hz ~25KHz Crossover High Pass 10Hz ~700Hz Signal to Noise > 90 dB Harmonic Distortion < 0,9 % THD Input Sensitivity 0,2V Input Impedance 10K OHMS Impedance Output 1 OHM Consumption with Signal Musical 2,2A ~163A Consumption with Signal Bass 2,2A ~326A Dimensions (H x W x D) mm 77 x 222 x 217 mm Weight Kg 2,8 Kg   TECHNICAL SPECIFICATIONS CHARACTERISTICS EX 3500 EQ – 2 OHMS Number of Channels 1 RMS Power at 2 Ohm 12.6V 3500W RMS RMS Power at 4 Ohm 12.6V 2300W RMS RMS Power at 2 Ohm 14.4V 4000W RMS RMS Power at 4 Ohm 14.4V 2600W RMS Supply Voltage 9,5 ~ 15V Frequency Response 10Hz ~25KHz Crossover Low Pass 50Hz ~25KHz Crossover High Pass 10Hz ~700Hz Signal to Noise > 90 dB Harmonic Distortion < 0,9 % THD Input Sensitivity 0,2V Input Impedance 12K OHMS Impedance Output 2 OHMS Consumption with Signal Musical 2,2A ~163A Consumption with Signal Bass 2,2A ~325A Dimensions (H x W x D) mm 77 x 222 x 217 mm Weight Kg 3,0 Kg

Read more less

EXPORT LINE STETSOM: An export-type product line that will please the world and Brazil.Developed for those looking for high performance and sound fidelity in automotive amplifiers with the most innovative electronic components.EXPORT LINE STETSOM. Performance to delight!EX 5000 EQ features:– EQ with three bands: BASS, MID BASS, MID HIGH, in addition to the traditional Level, High Pass and Low Pass features.Bass EQ: -10dB to +10dBMid-Bass EQ: -10dB to +10dBMid-High EQ: -10dB to +10dB– Frequency response from 10Hz to 15KHz and Cooler controlled by intelligent system. TECHNICAL SPECIFICATIONS CHARACTERISTICS EX 5000 EQ – 1 OHM Number of Channels 1 RMS Power at 1 Ohm 12.6V 5000W RMS RMS Power at 2 Ohm 12.6V 2800W RMS RMS Power at 1 Ohm 14.4V 5600W RMS RMS Power at 2 Ohm 14.4V 3400W RMS Supply Voltage 9,5 ~ 15V Frequency Response 10Hz ~15KHz Crossover Low Pass 50Hz ~15KHz Crossover High Pass 10Hz ~700Hz Signal to Noise > 90 dB Harmonic Distortion < 0,9 % THD Input Sensitivity 0,2V Input Impedance 26K OHMS Impedance Output 1 OHM Consumption with Signal Musical 4,1A ~245A Consumption with Signal Bass 4,1A ~490A Dimensions (H x W x D) mm 77 x 294 x 310 mm Weight Kg 4,1 Kg TECHNICAL SPECIFICATIONS CHARACTERISTICS EX 5000 EQ – 2 OHMS Number of Channels 1 RMS Power at 2 Ohm 12.6V 5000W RMS RMS Power at 4 Ohm 12.6V 3050W RMS RMS Power at 2 Ohm 14.4V 5500W RMS RMS Power at 4 Ohm 14.4V 3550W RMS Supply Voltage 9,5 ~ 15V Frequency Response 10Hz ~15KHz Crossover Low Pass 50Hz ~25KHz Crossover High Pass 10Hz ~700Hz Signal to Noise > 90 dB Harmonic Distortion < 0,9 % THD Input Sensitivity 0,2V Input Impedance 26K OHMS Impedance Output 2 OHMS Consumption with Signal Musical 3,1A ~240A Consumption with Signal Bass 3,1A ~480A Dimensions (H x W x D) mm 77 x 294 x 310 mm Weight Kg 4,1 Kg

Read more less

EXPORT LINE STETSOM: An export-type product line that will please the world and Brazil.Developed for those looking for high performance and sound fidelity in automotive amplifiers with the most innovative electronic components.EXPORT LINE STETSOM. Performance to delight!EX 8000 EQ features:– EQ with three bands: BASS, MID BASS, MID HIGH, in addition to the traditional Level, High Pass and Low Pass features.Bass EQ: -10dB to +10dBMid-Bass EQ: -10dB to +10dBMid-High EQ: -10dB to +10dB– Frequency response from 10Hz to 15KHz and Cooler controlled by intelligent system. TECHNICAL SPECIFICATIONS CHARACTERISTICS EX 8000 EQ – 1 OHM Number of Channels 1 RMS Power at 1 Ohm 14.4V 8000W RMS RMS Power at 2 Ohm 14.4V 4500W RMS Supply Voltage 9,5 ~ 15V Frequency Response 10Hz ~15KHz Crossover Low Pass 50Hz ~15KHz Crossover High Pass 10Hz ~700Hz Signal to Noise > 90 dB Harmonic Distortion < 0,9 % THD Input Sensitivity 0,2V Input Impedance 25K OHMS Impedance Output 1 OHM Consumption with Signal Musical 5,2A ~396A Consumption with Signal Bass 5,2A ~750A Dimensions (H x W x D) mm 77 x 294 x 445 mm Weight Kg 6,3 Kg TECHNICAL SPECIFICATIONS CHARACTERISTICS EX 8000 EQ – 2 OHMS Number of Channels 1 RMS Power at 2 Ohm 14.4V 8000W RMS RMS Power at 4 Ohm 14.4V 5110W RMS Supply Voltage 9,5 ~ 15V Frequency Response 10Hz ~15KHz Crossover Low Pass 50Hz ~15KHz Crossover High Pass 10Hz ~700Hz Signal to Noise > 90 dB Harmonic Distortion < 0,9 % THD Input Sensitivity 0,2V Input Impedance 26K OHMS Impedance Output 2 OHMS Consumption with Signal Musical 5,2A ~396A Consumption with Signal Bass 5,2A ~790A Dimensions (H x W x D) mm 77 x 294 x 445 mm Weight Kg 6,3 Kg

Read more less

Stetsom Fonte Automotiva 150A Power SupplyFree 3 Day Fedex Delivery Worldwide Stetsom's Fonte Automotiva series of power supplies was developed to offer maximum energy efficiency in battery charging and powering car audio equipment. Its intelligent charging system prevents premature battery wear, extending battery life and powering equipment continuously, preventing the batteries from getting discharged when in use.This is an excellent deal: competition level power for your system at a great price. TECHNICAL SPECIFICATIONS CHARACTERISTICS FONTE 150A Internal fuse AC input ✔ Output short circuit DC ✔ Supply Voltage 127Vac ~220Vac High Temperature ✔ Operating voltage DC 12,6V ~14,4V dc Impedance Output 150A @12,6V dc Consumption AC 127V: 30A / 220V: 18,5A Dimensions (H x W x D) mm 77,5 x 195 x 308 mm Weight Kg 3,23 Kg

Read more less

Stetsom Fonte Automotiva 200A Power SupplyFree 3 Day Fedex Delivery Worldwide Stetsom's Fonte Automotiva series of power supplies was developed to offer maximum energy efficiency in battery charging and powering car audio equipment. Its intelligent charging system prevents premature battery wear, extending battery life and powering equipment continuously, preventing the batteries from getting discharged when in use.This is an excellent deal: competition level power for your system at a great price. TECHNICAL SPECIFICATIONS CHARACTERISTICS FONTE 200A Internal fuse AC input ✔ Output short circuit DC ✔ Supply Voltage 127Vac / 200Vac High Temperature ✔ Operating voltage DC 12.6V ~ 14.4V Impedance Output 200A @ 12.6V Consumption AC 127V: 38A / 220V: 24.5A Dimensions (H x W x D) mm 77.5 x 260 x 308 Weight Kg 4.16 Kg

Read more less

Stetsom HL1200 - High Sonic Performance in a Compact PackageStetsom's latest HL line arrives to increase the efficiency, power and quality of mid-power stereo products. Designed to be the ideal choice in automotive sound systems, the HL line is perfect for complete projects or to enhance the low, mid and high frequencies in 4-way or more systems.Main features:Unparalleled Versatility: Developed to stand out in automotive sound projects, the Stetsom HL1200 offers exceptional versatility, making it the ideal choice for various system configurations.Powerful Performance: With a robust power of 1280 Watts RMS distributed over 4 channels, this digital amplifier provides powerful and clean sound performance.Advanced Technology: Built into a compact design, the HL1200 incorporates cutting-edge technology to deliver maximum efficiency, low distortion and a remarkably wide frequency response.Exceptional Signal-to-Noise Ratio: Guaranteeing immersive sound quality, the HL1200 boasts an excellent signal-to-noise ratio, providing clear audio without unwanted interference.Compact Construction: Despite its small size, this amplifier module maintains expressive power, offering an effective solution to optimize space without compromising sound quality.Elevate your listening experience with the Stetsom HL1200 Digital Amplifier Module. Compact, powerful and packed with technology to transform every note into an exceptional listening experience. TECHNICAL SPECIFICATIONS CHARACTERISTICS HL 1200.4 – 1 OHM Number of Channels 4 RMS Power at 1 Ohm 12.6V 4 x 300W RMS RMS Power at 2 Ohm 12.6V 4 x 200W RMS RMS Power at 1 Ohm 13.8V 4 x 350W RMS RMS Power at 2 Ohm 13.8V 4 x 250W RMS Power @ 12.6V Bridge 2 Ohms 2 x 600W RMS Power @ 13.8V Bridge 2 Ohms 2 x 700W RMS Supply Voltage 9 ~15V Frequency Response 10Hz ~ 26 KHz Crossover Low Pass 90 Hz Crossover High Pass 90 Hz Signal to Noise > 90 dB Harmonic Distortion < 0,9 % THD Input Sensitivity 0,2 V Input Impedance 14K Ohms Impedance Output 1 OHM Consumption with Signal Musical 57 A Consumption with Signal Bass 114 A Dimensions (H x W x D) mm 66 x 206 x 216 mm Weight Kg 1,94 Kg TECHNICAL SPECIFICATIONS CHARACTERISTICS HL 1200.4 – 2 OHMS Number of Channels 4 RMS Power at 2 Ohm 12.6V 4 x 300W RMS RMS Power at 4 Ohm 12.6V 4 x 165W RMS RMS Power at 2 Ohm 13.8V 4 x 320W RMS RMS Power at 4 Ohm 13.8V 4 x 170W RMS Power @ 12.6V Bridge 4 Ohms 2 x 600W RMS Supply Voltage 9 ~ 15V Frequency Response 10Hz ~ 26 KHz Crossover Low Pass 90 Hz Crossover High Pass 90 Hz Signal to Noise > 90 dB Harmonic Distortion < 0,9 % THD Input Sensitivity 0,2 V Input Impedance 14K Ohms Impedance Output 2 Ohms Consumption with Signal Musical 53 A Consumption with Signal Bass 106 A Dimensions (H x W x D) mm 66 x 206 x 216 Weight Kg 1,95 Kg

Read more less

Stetsom HL2000.4 - Power and Versatility in One Amplifier Designed for those seeking the highest performance and sound fidelity in car amplifiers, the HL2000.4 is a masterpiece delivering 2000W RMS across 4 robust channels of 500W RMS at 2 Ohms each. With versatile installation capabilities catering to diverse audio demands, this amplifier sets a new standard for automotive audio enthusiasts. Key Features: Impressive Power: With a total power of 2000W RMS, each of the 4 channels delivering 500W RMS at 2 Ohms provides a powerful and immersive sound experience. Versatile Installation: Engineered to adapt to different car audio setups, the HL2000.4 offers exceptional versatility, providing flexibility in installation. Independent Controls: The Front and Rear channels feature independent controls, including LEVEL for adjusting the input signal level and a Crossover with options for LOW-PASS, HIGH-PASS, or FLAT (FULL-RANGE). Superior Audio Quality: Enjoy unparalleled sound fidelity, allowing every note and musical detail to stand out for an immersive auditory experience. Robust Construction: With Stetsom's renowned quality, the HL2000.4 is built with high-quality materials, ensuring durability and consistent performance over time. Elevate the standard of your car audio system with the Stetsom HL2000.4 - an amplifier that combines exceptional power with intuitive controls for an unparalleled auditory experience. TECHNICAL SPECIFICATIONS CHARACTERISTICS HL2000.4 – 1 OHM Number of Channels 4 RMS Power at 1 Ohm 12.6V 4 x 435W RMS (STEREO) RMS Power at 2 Ohm 12.6V 4 x 280W RMS (STEREO) RMS Power at 1 Ohm 14.4V 4 x 545W RMS RMS Power at 2 Ohm 14.4V 4 x 365W RMS Power @ 12.6V Bridge 2 Ohms 2 x 870W RMS Power @ 13.8V Bridge 2 Ohms 2 x 1100W RMS Supply Voltage 9V ~15V DC Frequency Response 20Hz ~16KHz Crossover Low Pass 90Hz Crossover High Pass 90Hz Signal to Noise >90dB Harmonic Distortion >0,3 % THD Input Sensitivity 200mV Input Impedance 15K Ohms Impedance Output STEREO: 1 OHM / BRIDGE: 2 OHMS Consumption with Signal Musical 97A Consumption with Signal Bass 194A Dimensions (H x W x D) mm 77.5 x 235 x 240.5 mm Weight Kg 2.8 Kg CHARACTERISTICS HL2000.4 – 2 OHMS Number of Channels 4 RMS Power at 2 Ohm 12.6V 4 x 500W RMS (STEREO) RMS Power at 4 Ohm 12.6V 4 x 290W RMS (STEREO) RMS Power at 2 Ohm 13.8V 4 x 580W RMS (STEREO) RMS Power at 4 Ohm 13.8V 4 x 364W RMS (STEREO) Power @ 12.6V Bridge 4 Ohms 2 x 1000W RMS Power @ 13.8V Bridge 4 Ohms 2 x 1160W RMS Supply Voltage 9V ~ 15V DC Frequency Response 19Hz ~ 26KHz Crossover Low Pass 90Hz Crossover High Pass 90Hz Signal to Noise >90 dB Harmonic Distortion >0,3 % THD Input Sensitivity 200mV Input Impedance 15K OHMS Impedance Output STEREO: 2 OHMS / BRIDGE: 4 OHMS Consumption with Signal Musical 96A Consumption with Signal Bass 192A Dimensions (H x W x D) mm 77.5 x 235 x 240.5 mm Weight Kg 2,7 Kg

Read more less

Stetsom HL 800.4 Amplifier 800W RMS 4-Channels Car Audio Amplifier Developed for those seeking high performance and sound fidelity in automotive amplifiers, the HL800.4 is a 800W RMS product with 4 Channels of 225W RMS and great installation versatility. It features independent front and rear channels such as LEVEL to adjust the input signal level and Crossover, allowing you to choose between LOW-PASS, HIGH-PASS or FLAT (FULL-RANGE) operation.   TECHNICAL SPECIFICATIONS CHARACTERISTICS HL800.4 – 1 OHM Number of Channels 4 RMS Power at 1 Ohm 12.6V 4 x 226W RMS (STEREO) RMS Power at 2 Ohm 12.6V 2 x 144W RMS (STEREO) RMS Power at 1 Ohm 13.8V 4 x 260W RMS (STEREO) RMS Power at 2 Ohm 13.8V 4 x 204W RMS (STEREO) Power @ 12.6V Bridge 2 Ohms 2 x 430W RMS Power @ 13.8V Bridge 2 Ohms 2 x 520W RMS Supply Voltage 9V ~ 15V DC Frequency Response 20Hz ~ 22KHz Crossover Low Pass 90Hz Crossover High Pass 90Hz Signal to Noise >90dB Harmonic Distortion >0,3 % THD Input Sensitivity 200mV Input Impedance 15K OHMS Impedance Output STEREO: 1 OHM / BRIDGE: 2 OHMS Consumption with Signal Musical 52,5A Consumption with Signal Bass 105A Dimensions (H x W x D) mm 66 x 206 x 206 mm Weight Kg 1,7 Kg TECHNICAL SPECIFICATIONS CHARACTERISTICS HL800.4 – 2 OHMS Number of Channels 4 RMS Power at 2 Ohm 12.6V 4 x 225W RMS (STEREO) RMS Power at 4 Ohm 12.6V 4 x 140W RMS (STEREO) RMS Power at 2 Ohm 13.8V 4 x 260W RMS (STEREO) RMS Power at 4 Ohm 13.8V 4 x 165W RMS (STEREO) Power @ 12.6V Bridge 4 Ohms 2 x 450W RMS Power @ 13.8V Bridge 4 Ohms 2 x 520W RMS Supply Voltage 9V ~ 15V DC Frequency Response 10Hz ~26KHz Crossover Low Pass 90Hz Crossover High Pass 90Hz Signal to Noise >90 dB Harmonic Distortion >0,4 % THD Input Sensitivity 200mV Input Impedance 14K OHMS Impedance Output STEREO 2 OHMS / STEREO 4 OHMS Consumption with Signal Musical 44A Consumption with Signal Bass 88A Dimensions (H x W x D) mm 66 x 206 x 206 mm Weight Kg 1,7 Kg
